Up 7 Down 7 magazines Automatic Loader & Unloader
2018-12-16 03:04:50
In order to provide energy and reduce workload, these are customs made machine, they can hold 15 magazines (Up 7, Down 7, Lifter platform 1)
Main Specifications:
|
Conveyor Height:
|
950 ± 30 mm (For SMT application)
|
|
Flow Direction:
|
Left to right
|
|
Fixed Rail:
|
Front
|
|
Machine Interface:
|
SMEMA
|
|
Component clearance:
|
Top 25 mm, Bottom 25 mm
|
|
PCB Loading Time:
|
± 7 seconds
|
|
Magazine Change-over Time:
|
± 25 seconds
|
|
Pitch Control:
|
1-4, 10mm pitch
|
|
Magazine Capacity:
|
1 magazine on the lifter platform,
7 empty magazines on the upper/lower output magazine conveyor
7 full magazines on the lower/upper input magazine conveyor
|
|
Max total magazine weight:
|
50 kgs each (Or specify)
|
|
Power Supply:
|
AC220 ±10v, 50Hz
|
|
Air Supply:
|
5~6Kg/cm² (4~6 bar)
|
